Step-up converter, output 5~30V adjustable, Max 70W

$14.50

For lot orders, please contact us for prices

is a boost(step-up) power module, can accept 3.5~30VDC and generate 4~30VDC. Output voltage is always higher than input, difference is at least 0.5V.

Note: this converter requires user to have basic knowledge of electronics, we cannot provide educational service.
DO NOT adjust the output when the module is conneted to load, this may harm your load device, please fixed the output before connect to load.

Input range:3.5~30VDC
Output: 5~30VDC adjustable, higher than input.
Rated 3 Amp max, can achieve 6 Amp max for a short time.
Size: 6* 3 * 2cm
Non-load current:10mA (this number will be different according to different input and output)
Typical Effeciency:85% (this number will be different according to different input and output)
Working Ambient Temperature:-20 ~ +60℃
Typical Ripple:100mV p-p (this number will be different according to different input and output)
Overload protect point: 125~150% of rated power
Short circuit protection: Yes



Add to Cart:
Min:  2
