Low-cost Non-isolated DC/DC Converter Typical Parameters

Visit our online shop

Low cost DC-DC Converters has a big family, but their characters are mostly the same. This page shows the most common params.

Only 2 typical model is described, but they give an overview of this series of products. If you are looking for step-down/buck converter detail, you can refer to "36V to 12V DC-DC Converter". If you are looking for step-down/boost converter detail, you can refer to "12V to 24V DC-DC Converter". For example, most of the "36V to 12V converter" info are also correct for 48V to 12V converter, 24V to 5V converter etc.

36V to 12V,10A Buck DC-DC Converter
Size 74*71*27 mm
Rated Input 36VDC
Input Range 25-45 VDC
Max Non-load Consumption 0.2W
Output Voltage 12VDC
Output Current 10A
Ripple (max) 120mV
Max Output Power 120W * 110%
Load Regulation 1.5%
Allowed Case Temperature 75 ℃
Storage Temperature -20~80 ℃
Storage Humidity 20-90 %
Cooling method Breeze of Nature
Weight 250g
Full-load Efficiency >92%
Over Load Protection 110% of rated current limit

12V to 24V,8A Boost DC-DC Converter
Size 74*71*27 mm
Rated Input 12VDC
Input Range 11-15 VDC
Max Non-load Consumption 0.2W
Output Voltage 24VDC
Output Current 8A
Ripple (max) 200mV
Max Output Power 200W * 110%
Load Regulation 1.5%
Allowed Case Temperature 75 ℃
Storage Temperature -20~80 ℃
Storage Humidity 20-90 %
Cooling method Breeze of Nature
Weight 280g
Full-load Efficiency >92%
Over Load Protection 110% of rated current limit


12V to 24V, Step-up, 8A, 200W converter     12V to 33V, Step-up, 1.8A, 60W converter
12V / 24V to 5V, Step-down, 10A, 50W converter     12V to 24V, Step-up, 3A, 72W converter
12V to 24V, Step-up, 5A, 120W converter     12V to 24V, Step-up, 15A, 360W converter
12V to 55V, Step-up, 2A, 110W converter     12V / 24V to 5V, Step-down, 20A, 100W converter
12V / 24V to 5V, Step-down, 5A, 25W converter     24V to 12V, Step-down, 30A, 360W converter
24V to 12V, Step-down, 50A, 600W converter     24V to 12V, Step-down, 60A, 720W converter
24V to 12V, Step-down, 5A, 60W converter     24V to 12V, Step-down, 20A, 240W converter
24V to 12V, Step-down, 40A, 480W converter     24V to 12V, Step-down, 10A, 120W converter
8-40V to 24V, Step-up + Step-down, 72W converter     8-40V to 12V, Step-up + Step-down, 72W converter
10-30V to 33V, Step-up, 1.5A, 50W converter     24V to 48V, Step-up, 10A, 500W converter
36V to 12V, Step-down, 15A, 180W converter     48V to 60V, Step-up, 10A, 600W converter
12V to 48V, Step-up, 3A, 150W converter     12V to 48V, Step-up, 5A, 240W converter
48V to 12V, Step-down, 10A, 120W converter     36V to 5V, Step-down, 10A, 50W converter
48V to 5V, Step-down, 10A, 50W converter     36V to 12V, Step-down, 10A, 120W converter
12V to 36V, Step-up, 2A, 70W converter     24V to 13.8V, Step-down, 10A, 140W converter
24V to 13.8V, Step-down, 20A, 280W converter
